Blackmagic Design Blackmagic Audio Monitor 12G

Key Information:

•Model: Blackmagic Design Blackmagic Audio Monitor 12G
•Type: Professional audio monitoring device
•Connections: 12G-SDI, HDMI 2.0, Balanced XLR, Balanced AES/EBU, Unbalanced RCA
•Resolution: Supports up to 2160p60 (4K)
•Audio Outputs: Dual subwoofer and full range speakers

Detailed Specifications:

•Video Inputs:
•1 x 12G-SDI (with loop out)
•1 x HDMI 2.0
•Audio Inputs:
•2 x Balanced XLR
•2 x Balanced AES/EBU
•2 x Unbalanced RCA
•1 x 3.5mm stereo headphone jack
•Audio Outputs:
•Built-in stereo speakers with dual subwoofers
•1 x 3.5mm stereo headphone jack
•Video Outputs:
•1 x 12G-SDI loop out
•Supported Video Standards:
•SD, HD, and Ultra HD (up to 2160p60)
•Display:
•Integrated LCD screen for audio level monitoring
•Dimensions: 1RU rack mountable (19” wide)
•Weight: 2.22 kg (4.89 lbs)
•Power: 90 - 240V AC

How and Why This is a Great Product:

1. Superior Audio Quality:

•High-Fidelity Speakers: Equipped with full-range stereo speakers and dual subwoofers, the Blackmagic Audio Monitor 12G delivers exceptional audio clarity and depth, essential for accurate audio monitoring in professional environments.
•Multiple Audio Inputs: Supports balanced XLR, AES/EBU, and unbalanced RCA inputs, providing flexibility in connecting various audio sources.

2. Versatile Connectivity:

•12G-SDI and HDMI 2.0: The inclusion of 12G-SDI and HDMI 2.0 connections allows for high-resolution video monitoring up to 2160p60, making it compatible with a wide range of video equipment.
•Loop Out: The 12G-SDI loop out provides the ability to daisy-chain the signal to additional monitors or recording devices, enhancing workflow efficiency.

3. Comprehensive Monitoring Features:

•Integrated LCD Screen: The built-in LCD screen displays audio levels, making it easy to monitor audio performance in real time and ensure accurate sound levels.
•Professional Metering: Features accurate audio level metering, including VU, PPM, and Loudness meters, ensuring precise audio monitoring and compliance with broadcast standards.

4. Durable and Convenient Design:

•Rack Mountable: The 1RU rack-mountable design allows for easy integration into professional audio and video racks, saving space and ensuring a clean setup.
•Robust Build: Designed for professional use, the Blackmagic Audio Monitor 12G is built to withstand the rigors of live production and broadcast environments.

5. Flexible Power Options:

•Wide Voltage Range: Supports a wide range of input voltages (90-240V AC), making it suitable for use in various regions without the need for additional power converters.

6. Enhanced User Experience:

•User-Friendly Interface: The front panel features intuitive controls for input selection, volume adjustment, and audio metering, making it easy to use even in high-pressure live production scenarios.
•Headphone Output: The front-panel headphone output allows for personal monitoring, providing flexibility for operators in noisy environments.


The Blackmagic Design Blackmagic Audio Monitor 12G is an exceptional audio monitoring solution for professional environments. Its high-fidelity speakers, versatile connectivity options, and comprehensive audio metering make it an invaluable tool for accurate audio monitoring. The durable, rack-mountable design and user-friendly interface further enhance its appeal, making it a perfect choice for broadcasters, live event producers, and studio professionals who demand reliable and high-quality audio monitoring.
